Description
Power Pack LiFePO₄ 23S 72V 200Ah 1C With BMS Prismatic LFP Battery Pack
The Power Pack LiFePO₄ 23S 72V 200Ah 1C With BMS Prismatic LFP Battery Pack is a high-capacity rechargeable battery designed for industrial energy storage, backup power, and compatible high-voltage DC applications. Built using Lithium Iron Phosphate (LiFePO₄) prismatic cells, it offers high energy capacity, stable performance, and long service life when operated according to manufacturer specifications.
With a nominal voltage of 73.6V and a capacity of 200Ah, this battery pack provides approximately 14.72kWh of nominal energy. Its 23S configuration connects 23 prismatic cells in series, while the included Battery Management System (BMS) helps monitor and protect the battery during charging and discharging.
Key Features
Battery Chemistry: LiFePO₄ (Lithium Iron Phosphate)
Voltage Class: 72V
Nominal Voltage: 73.6V
Capacity: 200Ah / 200,000mAh
Nominal Energy: 14,720Wh (14.72kWh)
Configuration: 23S1P
Cell Type: Prismatic LFP cells
Discharge Rating: 1C
BMS: Included
Rechargeable battery for high-capacity applications
Suitable for compatible industrial and energy storage systems
Custom cables, connectors, and enclosure options according to requirements
Battery Configuration
23S1P: 23 prismatic cells connected in series.
Nominal voltage: 23 × 3.2V = 73.6V.
Capacity: 200Ah.
Nominal energy: 73.6V × 200Ah = 14,720Wh (14.72kWh).
Theoretical 1C discharge current: 200A, provided the cells and complete electrical system support this current.
BMS Protection
The included BMS helps manage battery operation. Depending on the selected model, protection functions may include:
Overcharge protection
Over-discharge protection
Overcurrent protection
Short-circuit protection
Cell voltage monitoring and balancing
Temperature monitoring, if supported
For the specified 1C rating, confirm that the BMS supports 200A continuous discharge. The cells, busbars, cables, fuses, and connectors must also be rated for the intended current.
Applications
Industrial energy storage systems
Solar energy storage with a compatible controller or inverter
Commercial backup power
Compatible high-voltage DC equipment
Industrial machinery and equipment
Specialty electric vehicles, where voltage-compatible
Custom high-capacity battery installations
Package Includes
23S 72V-class 200Ah prismatic LiFePO₄ battery pack
BMS
Power cables and connectors as specified in the order
Enclosure, if included in the selected configuration
Important Charging Information
Use a charger specifically designed for a 23S LiFePO₄ battery. The typical maximum charging voltage is 82.8V, based on 3.6V per cell, subject to the cell manufacturer’s specifications.
Before installation, confirm the charger’s voltage, BMS current rating, cable sizing, and the operating voltage range of the connected equipment. A device marketed as a “72V battery system” is not automatically compatible with a 23S LFP pack.
