Description
Power Pack LiFePO₄ 2S 6.4V 36000mAh 2S6P 3C With BMS 10A Discharge LFP Battery Pack
The Power Pack LiFePO₄ 2S 6.4V 36000mAh 2S6P 3C With BMS 10A Discharge LFP Battery Pack is a rechargeable Lithium Iron Phosphate battery designed for portable power, backup systems, electronics, robotics, lighting, instrumentation, and other low-voltage applications.
This battery uses a 2S6P configuration with 6000mAh LiFePO₄ cells, providing 6.4V nominal voltage and 36Ah capacity. It offers approximately 230.4Wh of energy and includes a 2S 10A BMS for battery protection.
Key Features
- Battery Chemistry: LiFePO₄ (LFP)
- Nominal Voltage: 6.4V
- Capacity: 36Ah / 36,000mAh
- Configuration: 2S6P
- Cell Capacity: 6000mAh / 6Ah
- Total Cells: 12
- Energy Capacity: Approximately 230.4Wh
- Cell Rating: 3C
- Theoretical 3C Current: 108A
- BMS Discharge Rating: 10A
- 2S LiFePO₄ BMS included
- Long cycle life
- Excellent thermal stability
- Rechargeable design
- Suitable for custom battery applications
2S6P Battery Configuration
The pack contains 12 LiFePO₄ cells arranged in a 2S6P configuration.
2S6P = 2 cells in series × 6 cells in parallel
Using 6000mAh cells:
- Series: 2
- Parallel: 6
- Total cells: 2 × 6 = 12
- Capacity: 6Ah × 6 = 36Ah
- Nominal voltage: 3.2V × 2 = 6.4V
- Maximum charge voltage: 3.6V × 2 = 7.2V
- Energy: 6.4V × 36Ah = 230.4Wh
- 3C theoretical current: 36Ah × 3 = 108A
BMS Protection
The included 2S LiFePO₄ 10A BMS provides protection for the battery pack.
Typical protection functions include:
- Overcharge protection
- Over-discharge protection
- Over-current protection
- Short-circuit protection
- Cell voltage protection
- Cell balancing, depending on BMS version
- Battery safety monitoring
10A Discharge BMS
The cells have a theoretical 3C current capability of 108A, but the battery uses a 10A discharge BMS. Therefore, the practical protected discharge current should be treated as up to approximately 10A, subject to the exact BMS specification and thermal conditions.
Charging Information
For this 2S LiFePO₄ battery:
- Nominal Voltage: 6.4V
- Maximum Charge Voltage: 7.2V
- Chemistry: LiFePO₄
- Recommended Charger: 2S LiFePO₄ CC/CV charger
- Recommended Charger Voltage: 7.2V
Do not use an 8.4V 2S Li-ion/NMC charger for this LFP battery.
Applications
- Portable electronic equipment
- LED lighting systems
- Backup power systems
- Robotics
- IoT equipment
- Monitoring equipment
- Security equipment
- Portable instruments
- Small DC systems
- Solar-powered devices
- Custom electronics
- OEM battery applications
Advantages
- 6.4V nominal voltage
- 36Ah high capacity
- 230.4Wh energy storage
- LiFePO₄ chemistry
- Excellent thermal stability
- Long cycle life
- Integrated 10A BMS protection
- 2S6P configuration
- Suitable for portable and backup applications
Package Includes
- 1 × 6.4V 36Ah LiFePO₄ battery pack
- 12 × LiFePO₄ cells
- 2S6P battery assembly
- 2S 10A LiFePO₄ BMS
- Busbars/interconnections
- Insulation and assembly materials
- Battery wires/connectors as specified
