Description
Power Pack LiFePO₄ 19S 60V 105Ah 19S7P 3C With BMS LFP Battery Pack
The Power Pack LiFePO₄ 19S 60V 105Ah 19S7P 3C With BMS LFP Battery Pack is a high-capacity rechargeable lithium iron phosphate battery designed for electric vehicles, industrial equipment, solar energy storage, inverter systems, and other high-power applications.
This battery uses a 19S7P configuration with approximately 15Ah LiFePO₄ cells, providing a total capacity of 105Ah. With a nominal voltage of 60.8V, it delivers approximately 6,384Wh (6.38kWh) of energy storage.
The integrated 19S LiFePO₄ BMS helps protect the battery from overcharge, over-discharge, over-current, short circuit, and cell imbalance.
Key Features
- Battery Chemistry: LiFePO₄ (LFP)
- Cell Type: LiFePO₄
- Configuration: 19S7P
- Nominal Voltage: 60.8V
- Capacity: 105Ah / 105,000mAh
- Cell Capacity: Approx. 15Ah
- Total Cells: 133
- Maximum Charge Voltage: 68.4V
- Energy Capacity: Approx. 6,384Wh / 6.38kWh
- Discharge Rating: 3C
- Theoretical 3C Current: 315A
- BMS: 19S LiFePO₄ BMS
- Long cycle-life LFP chemistry
- Excellent thermal stability
- High-capacity configuration
- Custom connector and wiring options
19S7P Battery Configuration
The battery uses a 19S7P configuration:
- 19 cells/groups connected in series
- 7 cells connected in parallel per group
- Total cells: 19 × 7 = 133
- Cell capacity: approximately 15Ah
- Pack capacity: 15Ah × 7 = 105Ah
- Nominal voltage: 3.2V × 19 = 60.8V
- Maximum charge voltage: 3.6V × 19 = 68.4V
- Energy capacity: 60.8V × 105Ah = 6,384Wh
BMS Protection
The integrated 19S LiFePO₄ BMS helps provide:
- Overcharge protection
- Over-discharge protection
- Over-current protection
- Short-circuit protection
- Cell voltage monitoring
- Cell balancing
- Temperature protection, depending on BMS model
The BMS current rating should be selected according to the actual continuous and peak current requirements of the application.
Connector & Wire
The battery pack can be customized with:
- XT90 / XT150 connectors
- Anderson-style high-current connectors
- High-current terminals
- Custom charging connector
- Custom wire gauge
- Custom wire length
- Common or separate charge/discharge ports
Applications
- Electric scooters
- Electric bikes
- Electric three-wheelers
- Electric vehicles
- Golf carts
- Industrial electric vehicles
- Solar energy storage
- Solar inverter systems
- UPS and backup power
- AGV / AMR systems
- Robotics
- Industrial equipment
- Telecom backup systems
- Portable power systems
- OEM / ODM battery projects
Advantages
- High 105Ah capacity
- Approximately 6.38kWh energy storage
- 19S7P configuration
- LiFePO₄ chemistry
- Integrated BMS protection
- Excellent thermal stability
- Long cycle-life potential
- Suitable for high-energy applications
- Custom connectors and wiring available
- Suitable for OEM, wholesale and bulk requirements
Package Includes
- 1 × 19S7P 60.8V 105Ah LiFePO₄ Battery Pack
- 133 × LiFePO₄ cells
- 1 × 19S LiFePO₄ BMS
- Cell interconnections
- Protective insulation
- Battery pack assembly
- Output wiring and connector as specified
