Power Pack LiFePO₄ 1S 3V 18000mAh 1S3P 3C with BMS LFP Battery Pack
The Power Pack LiFePO₄ 1S 18000mAh 3C Battery Pack with BMS is a rechargeable lithium iron phosphate (LFP) battery designed for compatible low-voltage electronic devices, portable equipment, and custom power applications.
Featuring a 1S3P configuration, this battery pack uses three cells connected in parallel, assuming 6000mAh cells. It provides a capacity of 18000mAh (18Ah) at a nominal voltage of 3.2V, delivering approximately 57.6Wh of energy.
The integrated Battery Management System (BMS) helps manage and protect the battery. Depending on the selected BMS model, protection functions may include overcharge, over-discharge, overcurrent, and short-circuit protection.
With a specified 3C discharge rate, the theoretical discharge current is 54A. Actual continuous discharge capability depends on the cell specifications, BMS rating, wiring, connectors, and thermal conditions.
Note: A single-cell LiFePO₄ battery has a nominal voltage of approximately 3.2V, rather than exactly 3.0V. Confirm that your equipment supports the battery’s operating voltage.
Key Features
- Battery Chemistry: Lithium Iron Phosphate (LiFePO₄ / LFP)
- Nominal Voltage: 3.2V
- Battery Capacity: 18000mAh / 18Ah
- Configuration: 1S3P
- Total Cells: 3, assuming 6000mAh cells
- Energy Capacity: Approximately 57.6Wh
- Specified Discharge Rate: 3C
- Theoretical 3C Discharge Current: 54A
- BMS: Included
- Rechargeable: Yes
- Applications: Compatible low-voltage electronics and custom battery-powered equipment
Battery Configuration
| Parameter | Details |
|---|---|
| Series Configuration | 1S |
| Parallel Configuration | 3P |
| Total Cell Count | 3 |
| Capacity per Cell | 6Ah, assumed |
| Pack Capacity | 3 × 6Ah = 18Ah |
| Nominal Cell Voltage | 3.2V |
| Nominal Pack Voltage | 3.2V |
| Maximum Charging Voltage | Typically 3.6V |
| Total Energy | 3.2V × 18Ah = 57.6Wh |
3C Discharge Configuration
| Specification | Details |
|---|---|
| Battery Capacity | 18Ah |
| Discharge Rate | 3C |
| Theoretical Discharge Current | 18Ah × 3 = 54A |
| Approximate Power at Nominal Voltage | 172.8W at 54A |
| Continuous Discharge Capability | Depends on cell, BMS, wiring, connector, and cooling ratings |
Important: The theoretical 54A calculation does not guarantee continuous operation at this current. Verify that the cells and BMS can safely support the intended load.
BMS Protection
The battery pack includes a Battery Management System (BMS). Depending on the selected model, its protection functions may include:
- Overcharge protection
- Over-discharge protection
- Overcurrent protection
- Short-circuit protection
- Voltage monitoring
Confirm that the BMS is designed specifically for 1S LiFePO₄ chemistry and supports the required charge and discharge currents.
Connector & Charging Requirements
- Use a charger designed specifically for a single-cell LiFePO₄ battery.
- Typical maximum charging voltage: 3.6V, subject to cell specifications.
- Do not use a 4.2V charger intended for a single-cell NMC lithium-ion battery.
- Select cables and connectors according to the required current.
- Verify connector polarity before connecting the battery.
- Ensure the BMS and wiring are rated for the intended load.
Applications
- Compatible low-voltage electronic equipment
- Portable and specialized power devices
- Embedded electronics and instrumentation
- Custom battery-powered projects
- Compatible low-voltage backup systems
- Special-purpose equipment requiring a rechargeable LFP battery
Confirm that the connected equipment supports the battery’s operating voltage and current requirements.
Advantages
- Rechargeable LiFePO₄ chemistry
- High 18Ah capacity in a 1S3P configuration
- Approximately 57.6Wh nominal energy
- Integrated BMS for battery management
- Parallel-cell configuration for increased capacity
- Suitable for compatible low-voltage applications
Package Includes
- 1 × Power Pack LiFePO₄ 1S 18000mAh battery pack
- 1 × BMS, as specified in the product configuration
